Product overview
EvM6 series of circuit breakers are new upgraded circuit breakers researched and developed
by the company combined with the advantages of similar international products and demand of
domestic and international markets.
With insulation voltage up to 1000V, the circuit breaker is applicable for distribution systems
of AC50Hz, rated working voltage 690V and rated working current from 10A to 800A, used to
distribute electric power energy, protect circuits and power equipment against overload, short
circuit, undervoltage and so on, also can be used for infrequent startup of motor and protect it from
overload, short circuit or undervoltage.
It is featured with small size, high breaking, short flashover, etc., is the ideal product for users. It
can be vertically installed or horizontally installed.
EvM6DC series DC moulded-case circuit breaker (hereinafter referred to as circuit breaker) is
suitable for DC systems of rated voltage up to and including DC 1000V and rated current 10~800A,
used to distribute electric power energy, protect circuits and power equipment against overload,
short circuit and so on.
The products can be fed with wires from top and bottom, and it is polarity-free.
It complies with the standards IEC60947-2, GB14048.2, etc.
